Product Description
SLA04 45mm diameter tubular linear actuator

Product introduction

Aluminum alloy material, compact structure design, light weight, using DC motor gear deceleration, built-in micro switch, can realize automatic stop after travel; Travel can be customized, easy to install, easy to operate; Can replace hydraulic pressure, air pressure and other traditional mechanical push-pull products, green environmental protection; Widely used in aircraft, ships, luxury car seat back lift, massage chair massage table fire equipment medical equipment furniture and other products

Product Parameters

• Operating temperature -26°C to +65°C

• Aluminum alloy housing and aluminum alloy expansion tube (stainless steel travel tube is optional)• Protection level: IP54 or IP65•12, 24, 36, 48VDC• Built-in micro switch• Planetary gear• Stroke range: 20mm~700mm• Maximum thrust :1500N• Operating frequency 20%(high speed operating frequency 10%)• Maximum self-locking force 3000N• Maximum working life of 50,000 times

Product drawing

L1(minimum mounting distance) =250mm+ stroke
Stroke(mm)50100300500700
L1(minimum mounting distance)250350450650850
Weight(kg)1.11.21.62.12.6

Product speed and load
